The QR-NA 24V is a smoke alarm relay that can be connected wirelessly to the smoke alarm ASD-10QR or AHD-10QR heat alarm.

This relay coordinates a network of ASD-10QR smoke alarms and/or AHD-10QR heat alarms and can be connected to any fire alarm system or other external devices powered with 24V, such as door closers with free-swing function, revolving doors, automatic sliding doors and sirens.

• Connect via a potential free NO/NC contact.
• Wireless network of up to 48 smoke or heat alarms
• RF frequency 868

The QR-NA 12V is a smoke alarm relay that can be connected wirelessly to the smoke alarm ASD-10QR or the heat alarm AHD-10QR..

This relay coordinates a network of ASD-10QR smoke alarms and AHD-10QR heat alarms and can be connected to any regular security/intrusion system or other external devices powered by 12V.

• Connect via a potential free NO/NC contact.
• Wireless network of up to 48 smoke and/or heat alarms
• RF frequency 868

Remote control for ASD-10QR wireless interconnectable smoke alarms and AHD-10QR wireless interconnectable heat alarms.

Remote testing of each individual ASD-10QR smoke alarm or AHD-10QR heat alarm
Remote HUSH function (reduced sensitivity) for 10 minutes
Reset a false alarm for 10 minutes

A wirelessly connectable heat detector that operates for at least 10 years with a fixed 3V Lithium battery. The AHD-10QR can be wirelessly connected to the ASD-10QR smoke detector.

The professional transmit/receive frequency of 868 MHz, combined with microcontroller-controlled software, guarantees safe and reliable operation.

Connectable to a maximum of 48 detectors.

An ASD-RRC remote control is optionally available with this detector.

The AHD-10QR heat detector can be combined with the PPIB Plug & Play Installation Box. This contains a built-in 24V power supply. You can connect the PPIB to the mains, wirelessly connect it to the AHD-10QR, and thereby connect it to external devices such as door closers, swing doors, automatic sliding doors, and sirens.

This heat detector can also be used with the QR-NA. This is a 24V or 12V control panel that can be wirelessly connected to external devices via a potential-free NO/NC contact. Power supply not included.

A wirelessly connectable smoke alarm with a fixed 3V Lithium battery that operates at least 10 years. The ASD-10QR smoke alarm can be wirelessly connected tot the AHD-10QR Heat alarm.

The professional transmitting / receiving frequency of 868 MHz in combination with the software-controlled by a micro-controller, ensures a safe and reliable functioning.

Linkable up to 48 alarms.

Optionally available with this alarm is a handy remote ASD RRC.

The smoke alarm ASD-10QR can be combined with the PPIB Plug & Play Installation Box, which includes a built-in 24V power supply. You can connect the PPIB to the mains, wirelessly link it to the ASD-10QR, and thereby connect it to external devices such as door closers, revolving doors, automatic sliding doors, and sirens.

This smoke alarm can also be used with the QR-NA, which is a 24V or 12V control panel that can be wirelessly connected to external devices using a potential-free contact NO/NC. Power supply not included.

The ASD-10Q is a quality smoke alarm manufactured in Europe, which of course is certified according to the latest EN14604 regulations.

Q-label also ensures that the smoke alarm meets a number of enhanced quality criteria as specified in the VdS3131 / vfdb14-01 directive.

The unique and controlled by a micro-controller LTD function (dust-compensation) reduces the probability of a false alarm.

Certification:
KRIWAN EN-14604, CE, VdS3131/vfdb 14-01, Federatie Veilig Nederland, for use in accordance with DIN14676.

The Smart Kitchen Timer is your smart kitchen assistant — designed to make cooking safer, easier, and completely stress‑free. With intelligent timing, clear alerts, and reliable performance, it helps prevent fire hazards before they can occur. Perfect for busy households, seniors, students, or anyone who wants extra peace of mind while cooking.
