Angebotsspektrum

H40-044-60-250

H40-044-60-250

Industrial Unmanaged 4-Port 60W PoE + 2-Port SFP + 2-Port RJ45 PoE Switch

The H40-044-60-250 is a Gigabit PoE solution for the outdoor environment and offers four of 10/100/1000BASE-T ports featuring 60-watt UPoE. Further empowering the units are 2 additional Gigabit copper ports and another 2 extra SFP fiber slots for uplink.

With a total PoE power budget up to 250 watts, the H40-044-60-250 meets the demand of high-power PoE for IP surveillance applications such as outdoor PTZ Speed Dome camera, License Plate Recognition(LPR) camera with high- power illuminator, and outdoor camera supporting cold start function.

The H40 series of Industrial Unmanaged PoE Switches supports IP67, 6KV surge protection for each Ethernet port, 40KV surge protection in AC power, and harden-graded construction to ensure operation in harsh weather conditions ranging from -40°C to 60 °C.

The H40 series has three sub-models, each classified as easy-to-install power source equipment (PSE) and providing power of up to 30W or 60W per port.

Angebotsspektrum

P2000-AIW

P2000-AIW

Professional 24VAC Cold Start Camera Housing w/Wiper

The camera housings are constructed from cast aluminum to meet IP66 and IK10 standards. The enclosures are spacious for wide-angle lenses or long-distant remote focus lenses.The P20 series supported 24VAC power input are professional models, all of which are equipped with window heater & blower. There are also additional side-opening alarm switch, an adjustable sunshield, an ITB (Illuminator Touch Board) concealing the wiring for optional vari-IR illuminator inside these products. P2000-AIW is especially equipped with camera heater, supporting cold start in the environment of -40°C. Meanwhile, there is also built-in wiper along with the enclosure. The optional water tank&pump (TB-100) is available for the sophisticated projects and tenders requirement.

Angebotsspektrum

XE22-120-TX

XE22-120-TX

2 Port Outdoor EPoC TX adapter

EPoC (Ethernet & Power over Coax) line is a long-reach solution providing Fast Ethernet and PoE over RG6 coaxial cable up to 1200m(3937ft) for any brand of PoE IP camera. This product line also is often used to upgrade legacy of CCTV to IP surveillance without changing legacy RG59/RG6 coaxial cable. Furthermore, outdoor EPoC solution is a rugged and economical alternative to optical fiber. In addition, the power over coax to remote PoE IP camera is more convenient than optical fiber solution.

Unternehmensprofil

AETEK, founded in March, 2015, New Taipei City, Taiwan, is a professional developer and manufacturer for IP surveillance technology, formulating a variety of PoE product lines and adaptive peripherals to function with various brands of IP cameras in the same network environment.

We provide cutting-edge camera housings for box cameras, even equipped with long-ranged varifocal 8-80 mm lens. Besides 24VAC models, AETEK's 95W PoE models can be operational over one Ethernet cable (CAT.5), powering the camera, supporting the function of demisting, cold start, blower, illuminator and wiper at the same time. The additional water tank with pump is also available by project requirement.

Besides the common 5/8/16/24 ports unmanaged PoE switches, AETEK develops an unique group of L2 Smart & L2+ managed switches with Devices Management Software (DMS). This DMS program can greatly simplify the installation and management thru GUI, making PoE switches to easily control the ONVIF-S-complying IP cameras. Additionally, rugged outdoor 5/8 ports with 30W PoE & 60W UPoE switches with surge protectors are the exceptional options for the projects under the extreme environment.

For bettering the installation efficiency, AETEK also has the innovative 1-1 & 1-2 indoor/ outdoor PoE extenders, which is the epoch-making 95W/60W/30W PoE PSE extenders, prolonging the operation range of high-power-consuming PDs, such as Speed Dome cameras or PVM (Public View Monitor).
